Axiomtek - a world-renowned leader relentlessly devoted to the research, development, and manufacturing of innovative and reliable industrial computer products of high efficiency – is proud to announce its tBOX110, a compact fanless transportation embedded system now EN 45545-2, EN 50155 certified. The tBOX110 is designed with low power consumption and heavy-duty construction that can withstand challenging day-to-day operational conditions. It accommodates varying voltage demands, effortlessly adapting to different environments. The reliable transportation system supports 12/24 VDC typical automotive power input with smart ignition, or 24 to 110 VDC for railway use and a wide-range 9 to 36V DC power input for general purposes. The tBOX110 is powered by the Intel Atom® x5-E3940 processor and has a wide operating temperature range of -40°C to +70°C and 3Grms vibration resistance. Its comprehensive verification and certification provide a more sustainable and safer solution for transportation applications.
The DIN-rail and wall-mountable tBOX110 measures only 164 x 128 x 44 mm and weighs 1.0 kg. The compact size ensures that it can fit in various space-constrained environments. The tBOX110 is equipped with one DDR3L-1866 SO-DIMM for up to 8GB of system memory. It also has one internal 2.5” SATA drive and one mSATA for extra storage needs. There are two full-size Rev.1.2 PCI Express Mini Card slots – one USB/PCIe with external SIM socket and one mSATA/USB/PCIe with external SIM socket – for high integration. Equipped with smart ignition power control, the tBOX110 enables to schedule power on/off events to protect the vehicle battery from unstable voltage and supports different power modes.
"Axiomtek's tBOX110 offers comprehensive transportation gateway solutions, catering to a wide range of applications, from in-vehicle to railway. This transportation-grade embedded system not only meets ISO 7637-2 standards but also has full certification to EN 45545-2 and EN 50155. By choosing the tBOX110, customers can benefit from significant cost savings and reduced waiting time, since they have no longer needed to bear verification fees or lengthy certification processes. This makes the tBOX110 a highly efficient and reliable choice for transportation-related projects," said Violet Hsu, product manager of the Product PM Division at Axiomtek. "With the innovative and reliable safe shutdown feature, the tBOX110 safeguards critical components and data during power disruptions or emergencies. Customers could also easily setup power on/off scheduling in the BIOS menu. It ensures the longevity and optimal functionality of the devices as well as making tBOX110 a responsible and environmentally conscious choice for energy saving solution."
The tBOX110 also offers rich I/O interfaces to ensure seamless connectivity and performance across transportation applications. For in-vehicle applications, the tBOX110 features two RS-232/422/485 with shield grounding, two isolated CANBus with SocketCAN, two RJ-45 10/100/1000 Mbps Ethernet ports (Intel® I210-IT), and one DB9 8-bit programmable DIO. While for railway applications, it offers four isolated RS-232/422/485 with shield grounding, two M12 A-coded 10/100/1000 Mbps Ethernet ports (Intel® I210-IT), two M12 X-coded 10/100/1000/10000 Mbps Ethernet ports (Intel® I210-IT), and one isolated 4-in/4-out DIO (terminal block). Two HDMI 1.4b with keylock, two USB 3.0, one reset button, one power button, one remote switch, and four antenna openings are available. Moreover, the tBOX110 is compatible with Windows® 10 64-bit and Ubuntu 20.04.
The tBOX110 is available now. For more product information or customization services, please visit our global website at www.axiomtek.com or contact one of our sales representatives at info@axiomtek.com.tw.
Advanced Features of tBOX110:
- EN 45545-2 and EN 50155 certified; ISO 7637-2 compliant
- Intel Atom® x5-E3940 processor
- Fanless and wide operating temperatures from -40°C to +70°C
- Supports 9 to 36VDC and 12/24VDC typical in-vehicle power input
- Supports 24 to 110VDC for railway power input
- Compact size with multiple COM, CANBus, and DIO for communication
- Smart Ignition for power on/off schedule, vehicle battery protection, and different power modes
