Axiomtek – a world-renowned leader relentlessly devoted to the research, development, and manufacturing of innovative and reliable industrial computer products of high efficiency – is pleased to introduce the MANO566, a robust Mini-ITX motherboard, boasting versatile I/O expansion capabilities. Powered by the 14th/13th/12th gen Intel® Core™ i9/i7/i5/i3 processor paired with the Intel® Q670E/R680E/H610E chipset, it delivers outstanding processing efficiency. The MANO566 ensures efficient data handling with a variety of I/O options such as four COM and eight USB ports, promoting seamless communication among diverse devices, sensors, and systems. It is well-suited for kiosk solutions in smart retail and industrial IoT applications, showcasing excellence in both performance and adaptability.
“Axiomtek’s MANO566 maximizes performance with its two 260-pin DDR4-3200 MHz slots, supporting up to 64GB. A PCIe x16 Gen5 slot provides users with the flexibility to easily enhance visual data processing for legacy automation control devices, machine vision, and entry-level medical imaging. Additionally, the MANO566 supports an M.2 Key M 2280 slot for SATA storage modules, an M.2 Key B 3052/3042 slot for 5G modules, and an M.2 Key E 2230 slot for Wi-Fi/Bluetooth modules. In addition, it features two GbE LAN ports to ensure swift and reliable connectivity when connecting sensors for manufacturing or conducting real-time quality inspections,” said Pure Yen, a Product Manager of the IDS Team at Axiomtek.
The MANO566 supports the Intel® UHD Graphics 700 series engine. It can handle up to four independent displays with DisplayPort++, eDP, and two HDMI interfaces, facilitating multitasking in computing workflows while delivering advanced graphics performance. Furthermore, this robust Mini-ITX board boasts various I/O functionalities, including four USB 3.2 ports, four USB 2.0 ports, two GbE LAN ports, four COM ports supporting RS-232/422/485, two SATA-600 ports, and an audio port. These comprehensive I/O interfaces not only improve inter-device connectivity but also maximize port utilization for efficient and versatile automation applications.
Moreover, the high-performance MANO566 is equipped with a 24+4-pin ATX connector featuring an AT mode auto-power function. To ensure consistent and reliable operation, it boasts a wide operating temperature range from 0°C to 60°C. The MANO566 additionally has an onboard Trusted Platform Module (TPM) 2.0 and a watchdog timer, enhancing security and ensuring system reliability.
Advanced Features of MANO566
- LGA1700 socket 14th/13th/12th gen Intel® Core™ i9/i7/i5/i3 processor
- Intel® Q670E/R680E/H610E chipset
- 2 DDR4 SO-DIMM for up to 64GB of memory
- 4 USB 3.2, 4 USB 2.0, and 4 COM ports
- 2 SATA-600 and 1 M.2 Key M 2280
- 1 PCIe x16, 1 M.2 Key E 2230, and 1 M.2 Key B 3052/3042
The MANO566 is now available for purchase. For more product information or pricing, please visit Axiomtek’s global website at www.axiomtek.com or contact our sales representatives at info@axiomtek.com.tw.
